RFID Glass Tag with Syringe
Short Description:
The RFID Animal Syringe Tag is an innovative solution designed for precision veterinary care and livestock management. Engineered with a lightweight, miniaturized form factor, making it ideal for pets, farm animals, and wildlife monitoring. Equipped with a high-sensitivity RFID chip (supporting LF/HF protocols), it enables rapid data storage and long-range retrieval of critical information such as vaccination history, medication records, health metrics, and owner details.
Characteristic
|
Model |
RFID Glass Tube Tag |
|
Chip Type |
Read and
write |
|
Frequency(Adjust) |
LF:
134.2KHz HF:13.56MHz |
|
Protocol |
ISO 11785
& ISO 11784 / FDX-B/ ISO14443A |
|
Write
Times |
>
1,000,000 times |
|
Other
Size Available |
1.25*7mm,
1.4*8mm, 2*12mm, etc |
|
Material |
Biological
material coating coverage, Bio-glass, Anti-bacterial, Anti-allergy |
|
Anti-static |
Anti-electrostatic
breakdown, Anti-pressure above 5000V |
|
Operating
Temperature |
-20°C ~
50 °C |
|
Storage
Temperature |
-40°C ~
70 °C |
|
Working
Time |
> 20
years |
|
Read
Range |
40 - 500
mm |
|
Syringe
Color |
Transparent |
|
Syringe
Material |
Polypropylene |
|
Packaging
Material |
Medical-grade
sterilization pouch |
|
Syringe
Sterilization |
EO Gas |
|
Operating
Temperature |
-10°C -
45°C |
|
Storage
Temperature |
-20°C -
50°C |
|
Period of
Validity |
5 years |
Features
Bio-compatible Materials:
Medical-grade glass ensuring animal safety.
Frequency Support:
Operates at 134.2KHz/13.56MHz, compliant with ISO11784/11785 ISO 14443Afor global reader compatibility.
Miniaturized Design:
Sizes are 1.25x7mm, 1.4x8mm, 2.12x12mm, lightweight for subcutaneous implantation in small/large animals.
Secure Data Storage:
EM4305/T5577/Ntag 216 chips and can ensure 10+ years of data retention.
Sterile Injection System:
Pre-filled syringes with ergonomic handles and clear scales enable precise implantation
Application
Pet Management:
Stores vaccination records for veterinary clinics to streamline pet healthcare.
Livestock Traceability:
Manage cattle/sheep from farm to slaughterhouse, ensuring compliance with food safety regulations.
Wildlife Conservation:
Non-invasive animal monitoring supports population studies, migration pattern analysis, and species protection without disrupting natural behaviors.
Upgrade animal management perfect for pets & livestock.
Contact us to know more details!
